Distribution Boards (DBs)
Distribution Boards (DBs)
Axiom Distribution Boards are essential electrical system components that control and distribute power to the various circuits throughout a building or facility, housing and organising protective devices safely.
A universal design allows flush or wall mounting, and an 8-tank phosphate process provides anti-rust conditioning. Side knockouts improve cable and conduit entry, and boards ship pre-configured with neutral links, earth links, bus bars and interconnecting wires/links. Removable top and bottom gland plates, mixed key-type and round-type mounting holes, an insulated 100A/200A busbar system and special cement-protected door packaging complete a robust, serviceable enclosure.
Key features
- Flush or wall mounting flexibility
- 8-tank phosphate process for anti-rust conditioning
- Side knockouts for flexible cable and conduit entry
- Neutral links, earth links, bus bars and links included
- Removable top and bottom gland plates
- Insulated 100A/200A busbar system
- Corrosion-resistant construction
Technical specifications
| Specification | Details |
|---|---|
| Configurations | 4, 6, 8, 12, 16 ways |
| Variants | SPN, TPN, Vertical, Phase Selector, TV/Tel, Cross, Plug-n-Socket |
| Voltage rating | 240/415V AC, 3 Phase / 4 Wire |
| Protection level | IP 30 (single-door), IP 43 (double-door) |
| Standards | IS 8623, IS 13032 |
| Operating temperature | −5°C to 40°C |
Recommended applications
Residential, commercial and industrial power distribution — organising and protecting final circuits in custom configurations.
Frequently asked questions
Yes. Axiom designs custom distribution boards to match the circuit count, ratings and layout your installation requires.
They are built with an 8-tank phosphate anti-rust process and advanced safety features for long, dependable service.
They accept Axiom MCBs, RCCBs, isolators and changeover switches on standard DIN rail.
